Make sure you allow fully the GYRO set up prior to moving….
Key Features
- Superb low speed performance.
- Switchable 3-mode gyro stabilisation system.
- Perfect for basic training.
- Fully aerobatic.
- Takes a standard 3S 2200 3200mAh LiPo.
- Durable wire undercarriage with solid mountings.
- Aerodynamically efficient swept winglets.
- Flap-equipped.
- Made from lightweight, durable EPO foam.
- Screw together assembly (no glue needed).
- Spacious battery compartment.
- Supplied with pre-fitted motor, ESC and servos.
- Features LED wingtip navigation lights.
- Numerous moulded scale fittings.
- Float set included.
What’s in the Box
- 1x Factory assembled and decorated fuselage and fin.
- 1x Factory assembled and decorated 2-piece wing.
- 1x Factory assembled and decorated tailplane.
- 1x Pre-installed 3536 850KV motor.
- 1x Pre-installed 30A ESC with XT60 connector.
- 6x Pre-installed high quality 9g metal gear servos.
- 1x Pre-installed high quality 13g metal gear servo (nose wheel).
- 1x Undercarriage set with wheel spats.
- 1x 2-blade 11 x 7″ propeller and spinner.
- 1x Wing spar.
- 1x Screw and pushrod set.
- 1x Wing strut set.
- 1x Scale aerial set.
- 1x Comprehensive instruction manual.
Needed to Complete
- 1x 6-channel transmitter and receiver combo.
- 1x 3S 2200 to 3200mAh LiPo with XT60 connector.
- 1x 3S compatible LiPo balance charger.
Product Description
In days of old, learning to fly usually meant accepting a trainer that resembled a shipping container with wings. How times have changed. Based on the Tecnam P2010 four seater, Arrows latest is not only the perfect fixed-wing tutor – tough, stable and forgiving – it looks sensational and will take you from tentative early circuits to full-house aerobatics. Using a bog-standard 3S 2200mAh LiPo the flap-equipped Tecnam is also cheap to run and, at a gnat s whisker shy of 58 span, large enough to make an impression. Best of all it comes with the Vector switchable stabilisation system pre-installed. Truly, the prospect of learning to fly has never looked so good and, for that matter, neither has stooging around on a calm day taking in some aeros . Lovely.
Specification:
| Wingspan (mm): |
1450 |
| Length (mm): |
1110 |
| Motor (KV): |
850 |
| Rec’d battery: |
3S 2200 – 3200mAh |
| ESC (A): |
30 |
| All-up weight (g): |
1280 |
Manuals & Parts Explosions
Airplane Technical Specifications
Weights & Dimensions
| Shipping Weight |
4.60kg |
10.14lbs |
|
| Product Length |
1,110mm |
43.7in |
| Product Wingspan |
1,450mm |
57.1in |
| Product Wing Area |
30dm2 |
464in2 |
|
|
| Connector |
XT60 |
| Completion Level |
PNP |
| Experience Level |
Beginner / Intermediate |
| Assembly Time |
30min |
| Recommended Usage Environment |
Outdoors / large field / lake |
| Channels |
6 |
| Colour |
White |
| Material |
EPO |
Included
| Motor/Engine |
3536 850KV brushless outrunner |
| Servos |
7x Digital 9g |
| ESC |
30A with XT60 connector |
